F580Plus 白墨喷码机
Product Introduction
FASTJET has designed the F580 small character inkjet printer to address applications that require bright and easy to read variable data codes on dark surfaces such as electrical cable, colored glass, motor parts and circuit boards. The F580 is capable of printing with high contrast pigmented inks, with bright, clear text in multiple languages and symbols, custom logo, graphics and many barcodes types.
Product Features
Stronger automatic cleaning function
Dynamic ink circulation system
Automatically adjust the circulation stirring time
Integrated filter design
Integrated design of quickly detachable spray head module
Visualization of consumable remaining quantity
Printing Effects
Product Parameters
Technical Parameters
| F580 Configuration and Parameters | |
| Nozzle | 50/60/70um |
| Maximum Printing Dot Matrix | 34 dot |
| Information Editing | WYSIWYG system, Chinese spelling input |
| Languages | Chinese, Chinese, Arabic, German, French, Portuguese, Spanish, etc. |
| Printhead | Temperature control printhead, diameter 41mm |
| Nozzle Material | Rubber |
| Protection Level | Optional IP55 |
| Communication Ports | Photoelectric sensor, encoder, USB port |
| Consumables Addition | plug-in consumable cartridge |
| Umbilical | Length 2700mm, Bending radius 30-40mm |
| Printing Height | 1.2-10mm |
| Maximum Printing Speed | 320m/min (60μm) |
| Contact-free Print Distance | 2-15mm |
| Input System | US keyboard layout |
| Selectable Dot Matrix Fonts | 5x5，7x5，9x6，8x8，11x8，12x11，15x12，16x11，24x16，32x22，9x6（粗体），11x8（粗体） |
| Operating Temperature | 5-45 °C |
| User Fields | QR Code, Bar Code, Logo, Picture, Clock,counter and shift etc. |
| Electrical | 200-240VAC, 50Hz |
| Power | Rated Power: 70W |
| Weight | Net weight: 27Kg, Grows weight: 40Kg (Including accessories and packing box) |
| Optional Interface | Three-color warning light, RS232 serial port, IO expansion module |
Product Dimensions (Unit: mm)
